| Availability: | |
|---|---|
Module Number | PH10 |
Pixel Pitch | 10 mm |
Physical Density | 10000 pixels/m2 |
Led Arrangement | 3 in 1 SMD |
LED Lamp | SMD3535 |
Scanning Mode | 1/4 Scan |
Module Resolution | 32*16 dots pixels |
Module Dimensions | 320*160 mm |
Cabinet size | W960*H960mm*150mm |
Cabinet material | Die-casting aluminum cabinet |
Brightness | ≧7500 CD |
Max Power Consumption | 800w/m² |
Ave Power Consumption | 200w/m² |
Viewing Angle | 160°(W) 160°(H) |
Operating Power source | 110-240V AC 50-60Hz |
Operating Temperature | -20ºC~+50ºC |
Refresh Rate | 1920Hz-3840HZ |
IP Rating | IP 65 |
Certificate | ETL, FCC, CCC, RoHS, CE |
MTPF | ≥100000hours |
HS Code | 8528591090 |
Maintenance | Front and Rear |
Installation | Hanging/ Stacking/ Fixed |
Warranty | 2 years |
Control Method | WiFi, 4G |
